1 GHz, 50 Ω, 5 V/A, 30 A Current Sensor

Features

• Advanced current sensor for TLP/HMM measurements
• High magnetic Amp x Second rating 3 Aµs, which results in e.g. maximum 30 A at maximum 100 ns pulse width
• Can be used for replacement Tek CT-1
• 30 kHz to 1 GHz bandwidth
• Very low parasitic load impedance 680 mΩ
• 5 V/A sensitivity at 50 Ω output
• Three 50 Ω SMA ports
• Compact size: 41 mm x 34 mm x 16 mm
• High reliability

Download: Product Datasheet CS-5V0
